Product Overview
Key Features of 16 Port GPON OLT
- 16 GPON ports with 1:128 splitting ratio
- 20KM physical reach / 60KM logical transmission
- Multi-service support: 4*10GE SFP+ + 8*GE RJ45 uplinks
- 104Gbps switching capacity & 77.376Mpps forwarding rate
- Advanced Layer 2/3 features: OSPF, BGP, ISIS, VRRP
- Dual power redundancy & modular power supply
- Robust security: DDoS protection, ARP spoofing prevention
- Universal ONU compatibility with batch upgrades
GPON OLT 16 Port GT1628 Technical Specifications
| Attribute | Specification |
|---|---|
| GPON Ports | 16×GPON (ITU-T G.984/G.988) |
| Uplink Ports | 8×10/100/1000M RJ45 + 4×10GE SFP+ |
| Switching Capacity | 104 Gbps |
| Packet Forwarding Rate | 77.376 Mpps |
| Power Input | AC 100-240V / DC 36-75V (Dual redundant) |
| Dimensions | 440mm(W)×44mm(H)×320mm(D) |
| Operating Temperature | -10°C to 55°C |
Advanced Capabilities
Networking & Security
- Layer 3 Routing: RIP, OSPF, BGP, ISIS
- VLAN Support: 4K entries with QinQ flexibility
- Carrier-grade redundancy: ERPS, MSTP, LACP
- Enterprise security: 802.1X, Radius/TACACS+, ACL policies
Management & QoS
- Multi-mode management: CLI, WEB, SNMP, SSH
- Advanced QoS: SP/WRR scheduling, DSCP marking
- Diagnostic tools: Ping, Traceroute, RMON, Syslog
Ordering Information
Model: GPON OLT 16PON GT1628
Configuration: 16 PON ports, 4×10GE SFP+ uplinks, 8×GE RJ45 ports, dual redundant power supply.
