Overview
1GE EPON Micro ONU Key Features
- High-Speed Connectivity: 1*GE port for gigabit wired connections.
- Compact Design: Small size (117mm x 88mm x 32mm) for flexible deployment.
- EPON Support: 1.25G upstream and downstream speeds with 20km transmission range.
- Advanced QoS: Traffic flow classification, priority marking, and rate limiting.
- Energy Efficient: Low power consumption (2.5W) with 12V/0.5A DC input.
- Advanced Security: IEEE 802.1x, CHAP/EAP authentication, and storm control.
Hardware Specifications
| Interfaces | 1*GE (RJ45), 1*EPON (SC/UPC) |
|---|---|
| Optical Parameters |
|
| Dimensions | 117mm x 88mm x 32mm (L x W x H) |
| Weight | Lightweight design for easy installation |
| Power Supply | 110-240V AC, 12V/0.5A DC |
1GE EPON Micro ONU Network Specifications
| PON Standards | IEEE 802.3ah, China Telecom EPON V2.1 |
|---|---|
| Data Rates | 1.25G Symmetric (Upstream/Downstream) |
| Protocol Support | IPv4, VLAN 802.1Q, IGMP Snooping, QoS |
Management & Security
| Management | Web, TELNET |
|---|---|
| Security | IEEE 802.1x, CHAP/EAP, Storm Control, Port Protection |
Environmental Specifications
| Operating Temperature | 0°C ~ 50°C |
|---|---|
| Storage Temperature | -40°C ~ 80°C |
| Humidity | 10% ~ 85% (non-condensing) |
