| Ports |
24*10/100/1000M Base-T，4*1000M Base-X SFP/10GE SFP+
|
| Exchange capacity |
128Gbps
|
| Packet forwarding rate |
95Mbps
|
| Multicast |
1K
|
| Route |
512
|
| Memory and storage |
Memory：512MB, storage：32MB
|
| power |
AC： 100～240V 47/63Hz；
DC： 36V～75V；
|
| Power consumption |
≤22W
|
| weight |
≤3kg
|
| Dimensions |
440X210X44mm
|
| Environment temperature |
Working Temperature：-10℃～55℃
Storge temperature：-40℃～70℃
|
| VLAN |
Support 4K VLAN
Support Vlan based on port, MAC and protocol
Support dual Tag VLAN, port-based static QinQ and fiexible QinQ
|
| MAC |
16K Mac address
Support static MAC address setting
Support black hole MAC address filtering
Support port MAC address limit
|
| ring network protocol |
Support STP/RSTP/MSTP
Support ERPS Ethernet ring network protection protocol Support Loopback-detection port loopback detection
|
| Port aggregation |
Support static link aggregation
Support dynamic LACP
Each aggregation group supports a maximum of 8 ports
|
| Mirroring |
Support port mirroring
Support stream mirroring
|
| QOS |
Support flow rate limiting function based on custom business flow
Supports mirroring and redirection functions based on custom business flows
Support priority marking based on custom service flow, support 802.1P, DSCP priority Remark capability Support port-based priority scheduling function,
support queue scheduling algorithms such as SP/WRR/SP+WRR
|
| Safety |
Support user hierarchical management and password protection Support IEEE 802.1X authentication
Support Radius&TACACS+ authentication
Support MAC address learning limit, support black hole MAC function Support port isolation
Support broadcast message rate suppression
Support IP Source Guard Support ARP flood suppression and ARP spoofing protection
Support DOS attack and virus attack protection
|
| Layer 3 |
Support ARP learning and aging
Support static route
Support dynamic route RIP/OSPF/BGP/ISIS
Support VRRP
|
| System management |
CLI、Telnet、WEB、SNMP V1/V2/V3、SSH2.0
Support FTP,TFTP file upload and downdload
Support RMON
Support SNTP
Support system work log
Support LLDP neighbor device discovery protocol Support 802.3ah Ethernet OAM
Support RFC 3164 Syslog
Support Ping and Traceroute
|
